General Linux OS Tuning for AMD EPYC

Step 1: Turn off swap
Turn off swap to prevent accidental swapping. Do not that disabling swap without sufficient memory can have undesired effects

swapoff -a

Step 2: Turn off NUMA balancing
NUMA balancing can have undesired effects and since it is possible to bind the ranks and memory in HPC, this setting is not needed

echo 0 > /proc/sys/kernel/numa_balancing

Step 3: Disable ASLR (Address Space Layout Ranomization) is a security feature used to prevent the exploitation of memory vulnerabilities

echo 0 > /proc/sys/kernel/randomize_va_space

Step 4: Set CPU governor to performance and disable cc6. Setting the CPU perfomance to governor to perfomrnaces ensures max performances at all times. Disabling cc6 ensures that deeper CPU sleep states are not entered.

cpupower frequency-set -g performance
Setting cpu: 0
Setting cpu: 1
.....
.....
cpupower idle-set -d 2
Idlestate 2 disabled on CPU 0
Idlestate 2 disabled on CPU 1
Idlestate 2 disabled on CPU 2
.....
.....

References:

  1. Tuning Guard for AMD EPYC (pdf)

Turning ksm and ksmtuned off

In this blog, I will write on how to turn off KSM and ksmtuned since I do not need these services and save some unnecessary swapping activities on the disk.

What is KSM?

According to RedHat Site (8.4. KERNEL SAME-PAGE MERGING (KSM)),
Kernel same-page Merging (KSM), used by the KVM hypervisor, allows KVM guests to share identical memory pages. These shared pages are usually common libraries or other identical, high-use data. KSM allows for greater guest density of identical or similar guest operating systems by avoiding memory duplication……

KSM is a Linux feature which uses this concept in reverse. KSM enables the kernel to examine two or more already running programs and compare their memory. If any memory regions or pages are identical, KSM reduces multiple identical memory pages to a single page……

8.4.4 Kernel same-page merging (KSM) has a performance overhead which may be too large for certain environments or host systems. KSM may also introduce side channels that could be potentially used to leak information across guests. If this is a concern, KSM can be disabled on per-guest basis.

Deactivating KSM

# systemctl stop ksmtuned
Stopping ksmtuned:                                         [  OK  ]
# systemctl stop ksm
Stopping ksm:                                              [  OK  ]

To permanently deactivate KSM with the systemctl commands

# systemctl disable ksm
# systemctl disable ksmtuned

When KSM is disabled, any memory pages that were shared prior to deactivating KSM are still shared. To delete all of the PageKSM in the system, use the following command:

# echo 2 >/sys/kernel/mm/ksm/run

After this is performed, the khugepaged daemon can rebuild transparent hugepages on the KVM guest physical memory. Using # echo 0 >/sys/kernel/mm/ksm/run stops KSM, but does not unshare all the previously created KSM pages (this is the same as the # systemctl stop ksmtuned command).

References:

  1. Redhat – 8.4. Kernel Same-Page Merging (KSM)

Using vmstat for profiling

Taken from RHEL Performance Tuning Student Booklet

The vmstat command, if given no arguments, will print out the averages of various system statistics since boot. The vmstat command accepts two arguments. The first is the delay, and the second is the count. The delay is a value in seconds between output. The count is the number of iterations of statistics to report.

[root@lime ~]# vmstat 4 5
procs -----------memory---------- ---swap-- -----io---- --system-- -----cpu-----
r  b   swpd   free   buff  cache   si   so    bi    bo   in   cs us sy id wa st
0  0   2832 145216 194528 6772048    0    0     0     1    0    1  0  0 100  0  0
0  0   2832 145200 194528 6772048    0    0     0     1   44   45  0  0 100  0  0
0  0   2832 145208 194528 6772048    0    0     0     8   46   45  0  0 100  0  0
1  0   2832 145208 194528 6772048    0    0     0     0   44   46  0  0 100  0  0
0  0   2832 145208 194528 6772048    0    0     0     3   46   55  0  0 100  0  0
Category Statistics Definition
Process related r The number of processes waiting for runtime
Process related b The number of processes in uninterruptible sleep
memory swpd The amount of memory currently used in swap
spaces
memory free The amount of idle (immediately available)
memory
memory buff The amount of memory used as buffers
memory cache The amount of memory used as cache
swap: paging statistics si Pages of memory swapped in per second
swap: paging statistics so Pages of memory swapped out per second
io: block I/O statistics bi Blocks per second received from block devices
io: block I/O statistics bo Blocks per second sent to block devices
system in Interrupts raised per second
system cs Context switches per second
cpu: how CPU time is used us Percentage of time spent running user-space code
cpu: how CPU time is used sy Percentage of time spent running kernel code
cpu: how CPU time is used id Percentage of time spent idle
cpu: how CPU time is used wa Percentage of time spent blocked while waiting for
I/O to complete
cpu: how CPU time is used st Percentage of time where the CPU had a process
ready to run, but CPU time was stolen by the
hypervisor supporting this virtual machine
(typically because the CPU is being used by
another guest virtual machine)



Determine how many CPUs in the systems

I came across this sniffy forgotten tools to help determine the CPU information. I guess we are all familiar with top. But if you type “1” after top, you are able to see details in the individual

A. Using top

# top

top - 10:11:35 up 95 days, 20:02,  2 users,  load average: 0.51, 0.39, 0.20
Tasks: 326 total,   1 running, 325 sleeping,   0 stopped,   0 zombie
Cpu(s):  0.0%us,  0.1%sy,  0.0%ni, 99.9%id,  0.0%wa,  0.0%hi,  0.0%si,  0.0%st
Mem:  65951272k total, 65647784k used,   303488k free,   221504k buffers
Swap: 33046520k total,        0k used, 33046520k free, 63608900k cached

PID USER      PR  NI  VIRT  RES  SHR S %CPU %MEM    TIME+  COMMAND
13469 root      20   0 15172 1436  956 R  2.6  0.0   0:00.72 top
1 root      20   0 19352 1520 1208 S  0.0  0.0   0:01.58 init
2 root      20   0     0    0    0 S  0.0  0.0   0:00.01 kthreadd
..............
..............
1

top - 10:11:58 up 95 days, 20:03,  2 users,  load average: 0.46, 0.38, 0.21
Tasks: 310 total,   1 running, 309 sleeping,   0 stopped,   0 zombie
Cpu0  :  0.0%us,  0.3%sy,  0.0%ni, 99.3%id,  0.3%wa,  0.0%hi,  0.0%si,  0.0%st
Cpu1  :  0.0%us,  0.0%sy,  0.0%ni,100.0%id,  0.0%wa,  0.0%hi,  0.0%si,  0.0%st
Cpu2  :  0.3%us,  0.0%sy,  0.0%ni, 99.7%id,  0.0%wa,  0.0%hi,  0.0%si,  0.0%st
Cpu3  :  0.0%us,  0.0%sy,  0.0%ni,100.0%id,  0.0%wa,  0.0%hi,  0.0%si,  0.0%st
Cpu4  :  0.0%us,  0.0%sy,  0.0%ni,100.0%id,  0.0%wa,  0.0%hi,  0.0%si,  0.0%st
Cpu5  :  0.0%us,  0.0%sy,  0.0%ni,100.0%id,  0.0%wa,  0.0%hi,  0.0%si,  0.0%st
Cpu6  :  0.0%us,  0.0%sy,  0.0%ni,100.0%id,  0.0%wa,  0.0%hi,  0.0%si,  0.0%st
Cpu7  :  0.0%us,  0.0%sy,  0.0%ni,100.0%id,  0.0%wa,  0.0%hi,  0.0%si,  0.0%st
Cpu8  :  0.0%us,  0.0%sy,  0.0%ni,100.0%id,  0.0%wa,  0.0%hi,  0.0%si,  0.0%st
Cpu9  :  0.0%us,  0.0%sy,  0.0%ni,100.0%id,  0.0%wa,  0.0%hi,  0.0%si,  0.0%st
Cpu10 :  0.0%us,  0.0%sy,  0.0%ni,100.0%id,  0.0%wa,  0.0%hi,  0.0%si,  0.0%st
Cpu11 :  0.0%us,  0.0%sy,  0.0%ni,100.0%id,  0.0%wa,  0.0%hi,  0.0%si,  0.0%st
.........

B. Using lspcu to take a look at summary

# lscpu

Architecture:          x86_64
CPU op-mode(s):        32-bit, 64-bit
Byte Order:            Little Endian
CPU(s):                12
On-line CPU(s) list:   0-11
Thread(s) per core:    1
Core(s) per socket:    6
CPU socket(s):         2
NUMA node(s):          2
Vendor ID:             GenuineIntel
CPU family:            6
Model:                 45
Stepping:              7
CPU MHz:               2501.000
BogoMIPS:              4999.27
Virtualization:        VT-x
L1d cache:             32K
L1i cache:             32K
L2 cache:              256K
L3 cache:              15360K
NUMA node0 CPU(s):     0-5
NUMA node1 CPU(s):     6-11
