Options | Description |
-aas | start Fluent in server mode |
-act | load ACT Start page |
affinity=<x> | set processor affinity; <x>={core | sock | off} |
-app | launches the Remote Visualization Client |
-appscript=<scriptfile> | run the specified script in App |
-case <file_path> [-data] | reads the case file immediately after Fluent launches; can include the data file if it shares the same name as the case file |
-cflush | flush the file cache buffer |
-cnf=<x> | specify the hosts file |
-command=”<TUI command>” | run TUI command on startup, |
-driver <name> | sets the graphics driver; <name>={opengl | opengl2 | x11 | null} |
-env | show environment variables |
-g | run without GUI or graphics |
-gpgpu=<n> | specify number of GPGPUs per machine |
-gpu[=<n>] | run with GPU Solver, and specify devices to use as needed (where <n> is a comma-separated list of devices) |
-gr | run without graphics |
-gu | run without GUI |
-gui_machine=<hostname> | specify the machine to be used for running graphics-related process |
-h<heap_size> | specify heap size for Cortex |
-help | this listing |
-host_ip=<host:ip> | specify the ip interface to be used by the host process |
-i <journal> | read the specified journal file |
-license=<x> | specify the license capability; <x>={enterprise | premium} |
-meshing | run Fluent in meshing mode |
-mpi=<mpi> | specify MPI implementation; <mpi>={openmpi | intel | …}, |
-mpitest | run the mpitest program instead of Fluent to test the network |
-nm | don’t display mesh after reading |
-pcheck | check the network connections before spawning compute node processes |
-platform=intel | use AVX2 optimized binary; This option is for processors that can support AVX2 instruction set |
-post | run a post-processing-only executable |
-prepost | run a pre/post-processing-only executable |
-p<ic> | specify interconnect; <ic>={default | eth | ib}, |
-r | list all releases |
-r<x> | specify release <x> |
ANSYS
Updating ANSYS 2023R2 License Server Information for Linux Client using the command line
If you are updating ANSYS License Server Information for ANSYS Client using only the command line, do the following
# vim usr/local/ansys_inc/shared_files/licensing/ansyslmd.ini
SERVER=1055@IP_Address_Of_ANSYS_LIC_SVR
ANSYSLI_SERVERS=2325@IP_Address_Of_ANSYS_LIC_SVR
Make sure the 1055, 1056, 2325 Ports of the License Server are opened.
Licensing Errors for ANSYS IcePak Solver
If you are encountering issues like the one below.
"If you have this error "Failed to enable features using current license settings. Note that Pro, Premium, Enterprise licenses are available on your server. To use these licenses check the corresponding option. For more information, search "PPE" in the help documentation. Failover feature "ANSYS IcePak Solver" is not available. Request name aice_solv does not exist in the....."
Running ANSYS Workbench with Mesa OpenGL
If you are using mesa so that you can use MESA open-source software implementation of OpenGL on ANSYS Workbench, you may want to use the following command
% export LIBGL_ALWAYS_INDIRECT=1
% export LIBGL_ALWAYS_SOFTWARE=1
% runwb2 -oglmesa
Fixing can’t load screen14 issues for ANSYS 2020-R1
I was having this strange issue when running ANSYS ICEM
"Fixing can't load screen14 issues, using variable Signal 11 caught! Segmentation violation - exiting after doing an emergency save"
The Issue can easily resolved. It is due to errors due to missing fonts libraries
# yum install xorg-x11-fonts-* Loaded plugins: fastestmirror, langpacks Loading mirror speeds from cached hostfile * base: mirror.newmediaexpress.com * epel: download.nus.edu.sg * extras: mirror.newmediaexpress.com * updates: mirror.newmediaexpress.com Package xorg-x11-fonts-ISO8859-1-75dpi-7.5-9.el7.noarch already installed and latest version Package xorg-x11-fonts-Type1-7.5-9.el7.noarch already installed and latest version Resolving Dependencies --> Running transaction check ---> Package xorg-x11-fonts-100dpi.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-75dpi.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-ISO8859-1-100dpi.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-ISO8859-14-100dpi.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-ISO8859-14-75dpi.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-ISO8859-15-100dpi.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-ISO8859-15-75dpi.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-ISO8859-2-100dpi.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-ISO8859-2-75dpi.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-ISO8859-9-100dpi.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-ISO8859-9-75dpi.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-cyrillic.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-ethiopic.noarch 0:7.5-9.el7 will be installed ---> Package xorg-x11-fonts-misc.noarch 0:7.5-9.el7 will be installed --> Finished Dependency Resolution
The Issue should be resolved.
